For complex control functions in vehicles and mobile machines

With many multifunctional configurable input and output channels

High-performance CAN interfaces for various communication tasks

Programmable to IEC 61131-3 with CODESYS

E1 type approval by the Kraftfahrt-Bundesamt (German Federal Office for Motor Traffic) for use under difficult conditions

Construction Machinery、Sanitation Machinery、Port Machinery、Fire Machinery、Aerial work

Electrical data
Operating voltage	10...32 V DC
Inputs / outputs
Total number of inputs and outputs	64
Number of inputs	32
Number of outputs	32
Software / programming
Parameter setting options	input/output functions
PLC function to IEC 61131-3	yes
Tests / approvals
MTTF [years]	23
Ambient conditions
Ambient temperature[℃]	-40...85
Protection rating	IP 67 (for inserted connector with individually sealed cores, e.g. EC2084)
